Professional Router Bits
The shearing action of the US and UB series yields cleaner cuts with less energy and less
vibration than the standard straight bits. The helical ground razor-sharp cutting edges
provide superior finish. Spiral upshear geometry pulls the chips from the working area,
allowing deeper penetration with higher feed rates. The result is – long tool life during
CNC operations at an affordable price. The use of these tools can prove, in many cases,
to be more economical than the use of expensive spiral solid carbide tools. Using the
Chipbreaker (Semi-finishing) - UB - Up-Shear Bits allows even higher feed rates leaving a
relatively smooth surface finish. Designed for CNC machines, the tools are available with
large shank diameters.
Tool No.
D
B
B1
L
d=12mm d=1/2"
d=16mm d=20mm mm mm mm mm
2 Flutes
US25132
US25138
12.7
32
45
90
US27132
US27138
12.7
42
55
105
US25161
16.0
32
50
100
US27161
16.0
42
60
110
US2720E 20.0
42
60
120
2+2 Flutes
US28132
US28138
13.0
50
60
110
US2820E 20.0
50
65
125
CNC STRAIGHT PRODUCTION BITS
US3
3 Flutes
US2
2 Flutes
Tool No.
D
B
B1
L
d=16mm d=20mm mm mm mm mm
US35161
16.0
32
50
100
US3820E 20.0
50
65
125
UB2
2 Flutes with Chipbreaker.
For roughing and semi finishing.
Tool No.
D
B
B1
L
d=12mm d=1/2"
d=16mm d=20mm mm mm mm mm
2 Flutes
UB27132 UB27138
13.0
42
55
105
45
90
2+2 Flutes
UB28132 UB28138
13.0
50
60
110
60
110
UB3
3 Flutes with Chipbreakers
Tool No.
D
B
B1
L
d=16mm d=20mm mm mm mm mm
UB35161
16.0
32
50
100
UB3820E
20.0
50
65
125
