Professional Router Bits
NUS
Slot & Undercut Bit with Variable Depth
For general Slotting and undercutting. Suitable for flooring.
Exchangeable bearings enable achieving different depths of cut.
All assemblies are supplied with Torx Key T25.
B
Cutter
Tool No.
Assembly No.
mm
d=8mm d=12mm d=1/2"
Includes Cutter and arbor
3.0
N3U0300 NU03005* NU03002* NU03008*
4.0
N3U0400 NU04005 NU04002 NU04008
5.0
N3U0500 NU05005 NU05002 NU05008
6.0
N3U0600 NU06005 NU06002 NU06008
Includes Cutter, arbor and 4 bearings
3.0
N3U0300 NUS03045** NUS03042** NUS03048**
4.0
N3U0400 NUS04045 NUS04042 NUS04048
5.0
N3U0500 NUS05045 NUS05042 NUS05048
6.0
N3U0600 NUS06045 NUS06042 NUS06048
Tool No.
L
d=8mm d=12mm d=1/2" mm
NU79015
57
NU79012 NU79018 67
Ball Bearing
B420150 B350150 B320150 B280150
Slot Depth (C)
2.8 mm 6.3 mm 7.8 mm 9.8 mm
*For NU03005/2/8 use the corresponding arbor - NU79005/2/8
**For NU03045/2/8 use the corresponding arbor - NU79005/2/8
Replacement Torx screw - BT50080
Table for Choosing the bearing according to the desired slot
Arbors for Slot & Undercut Bit
NS
Variable Depth Set for Slotting Cutters
Includes arbor and 5 ball bearings for changing cut depths.
All Slotting cutters N3 type can be used. Cutter not included.
Set No.
C
Ball
Bearing
L
d=6mm d=1/4" d=8mm mm
mm
NS79053 NS79054 NS79055
2.8 B420150
70
6.3 B350150
7.8 B320150
9.8 B280150
12.8 B220080
Set No.
C
Ball
Bearing
L
d=12mm d=1/2" mm
mm
NS79052 NS79058
2.8
B420150
78
6.3
B350150
7.8
B320150
9.8
B280150
12.8 B220080
d
L
B
C
47.6mm
NS
d
L
B
47.6mm
C
NUS
d
L
B
47.6mm
C
NUS
d
B
47.6mm
NUO/NUS
L
