609 / 670
כרסמים לרוטר ושקענים
609
03-9529998 :
ראשל”צ טל
1
אדר יבוא ושיווק פרזול בע”מ רחוב דוד רזיאל
www.adrtrading.co.il03-9511511 :
פקס
2
AC3
Countersinks for Dowel Drills
Carbide Tipped
Right hand and left hand rotation.
Drills not included.
ACK
Countersinks - Combi System
Carbide Tipped.
HSS drill included.
ACF
Face Frame Counterbore
Carbide tipped.
HSS drill included.
Tool No.
D1
D
L
d
mm mm mm mm
ACK4007D 4.0
12.7
60
10x30
ACK5007D 5.0
12.7
60
10x30
Tool No.
D1
D
B
L
d
mm mm mm mm mm
ACFS950S 3.45
9.5
9
104
9
ACF2950S 3.45
9.5
9
152
9
Locking screw - BR60060 (M6 x 6), Allen key - KEY03.0 (3mm)
*Locking screw - BR40040 (M4 x 4), Allen key - KEY5/64 (2mm)
Locking screw - BR60050 (M6 x 5), Allen key - KEY03.0 (3mm)
Replaceable “Fish tail” drill - DR03450
Tool No.
D1
D
L
Right
Left
mm mm mm
Designed to be assembled on the drill flute
For individual drill Diameters
AC3040R AC3040L
4
15.5
18
AC3050R AC3050L
5
16
18
AC3060R AC3060L
6
16
18
AC3070R AC3070L
7
16
18
AC3080R AC3080L
8
18
18
AC3090R AC3090L
9
18
18
AC3100R AC3100L
10
20
18
AC3120R AC3120L
12
20
18
Designed to be assembled on the drill 10mm shank
Fits a range of drill Diameters
AC31112R AC31112L 11-12 22
17
AC35101R* AC35101L* 5-10 15.5
19
AC3510R AC3510L
5-10
20
19
7
C
AC3
Type A
D1
L
D
7
8
9
B
C
AC3
Type A
AC3
Type B
ACM
D1
D1
D1
D1
D
D
L
L
L
L
D
D
W.P.W.
W.P.W.
d
L
D
D1
ACK
±0.1
0<10
Degrees
50<=
10<50
טיפולטרמי
-
קושי
ק
"
מ
מק
"
ט
±1°
±0.3
±0.2
סיבולתכללית
אישר
ובץ
חומר
הנדסה בע
.
וו
.
פ
.
וו
"
מ
W.P.W. Engineering Lt
FILE NAME: DEGEM ETZ
DEGEM ETZ-DRILL-3
DRILL-1
±0.1
0<10
50<=
10<50
±0.3
±0.2
סיבולתכללית
הנדסה בע
.
ו
"
מ
W.P.W. Enginee
ACF
d
L
B
D
D1
